EG Edge Gateway

EG edge gateways

EDGE COMPUTING GATEWAY

Node-RED Visual Programming

Hot Products

Product Specifications

EG Series8200 Pro82008200 Mini8200 Lite82082000
Key FeatureHigh PerformanceMulti-interfaceStandard VersionDIN-rail VersionCNC VersionIEC104 VersionLow Cost8 Serial PortsLoRa Gateway
ProcessorOcta-core A55 @1.8GHzDual-core A7 @1.2GHzDual-core A7 @1.2GHzDual-core A7 @1.2GHzDual-core A7 @1.2GHzDual-core A7 @1.2GHzA7 @1.2GHzDual-core A7 @1.2GHzDual-core A7 @1.2GHz
Memory2GB512MB512MB512MB512MB512MB256MB512MB512MB
eMMC16GB4GB4GB4GB4GB4GB4GB4GB4GB
SD CardMax 128GB (optional)Max 128GB (optional)Max 128GB (optional)Max 128GB (optional)Max 128GB (optional)Max 128GB (optional)×Max 128GB (optional)Max 128GB (optional)
4G×√ (optional)√ (optional)
5G√ (optional)××××××××
HDMI××××××××
Ethernet Ports1×WAN + 1×LAN1×WAN + 1×LAN1×WAN + 1×LAN1×WAN + 1×LAN1×WAN + 1×LAN1×WAN + 1×LAN1×WAN/LAN1×WAN/LAN1×WAN/LAN
LoRa××××××××
Wi-FiDual-band Wi-Fi 6Dual-band Wi-Fi 6Dual-band Wi-Fi 6Dual-band Wi-Fi 6Dual-band Wi-Fi 6Dual-band Wi-Fi 6×××
GPS××××××××
USB2×USB 2.01×USB 2.0×××××××
RTC×
RS485322222281
RS232111111×××
CAN×2×××××××
DO22×××××8×
DI22×××××××
AO2××××××××
AI2××××××××
Operating Voltage9~36V9~36V9~36V9~36V9~36V9~36V9~36V9~36V9~36V
Operating Current500mA@12V280mA/12V150mA/12V150mA/12V150mA/12V150mA/12V60mA/12V170mA/12V180mA/12V
CertificationCECECECECECECECECE
Operating Temperature-40 ~ 85°C-40 ~ 85°C-40 ~ 85°C-40 ~ 85°C-40 ~ 85°C-40 ~ 85°C-20 ~ 85°C-40 ~ 85°C-40 ~ 85°C
Remote O&M
Remote Management
Remote Upgrade
Virtual Network Interface
Virtual Serial Port
Local Database×
Visual Programming
PLC Protocol×××
CNC Protocol××××××××
IEC 60870-5-104××××××××
Web Configuration××××××××
Industry ProtocolsCJ188/DLT645/HJ212/Modbus/OPC UA*/BACnet*/etc.IdenticalIdenticalIdenticalIdenticalIdenticalIdenticalIdenticalIdentical
Network ProtocolsMQTT / HTTP / TCP / UDP / WebSocket / Alibaba Cloud IoT Platform / OneNET / etc.IdenticalIdenticalIdenticalIdenticalIdenticalIdenticalIdenticalIdentical

Learn more about the EG2000 here.

Integration Guides

Step-by-step tutorials for connecting PLCs and industrial devices with EG Edge Gateway. A continuously growing knowledge base covering industrial automation integrations and protocols.

Product Features

EG8200 series products abstract complex hardware interfaces, different industrial network protocols, etc. into Nodes one by one. Users can use these Nodes flexibly to replace the traditional complex and inefficient coding process by dragging and connecting. Really let customers focus on business logic and quickly create their own gateway equipment. The mission of EG8200 series products is to continuously develop new Nodes to serve industry customers to adapt to the fragmentation of IoT industry needs.

Supports docking with various mainstream PLC brands, multiple IoT protocols, and industrial protocols, supports data format customization, logic customization, and is perfectly compatible with private protocols and niche protocols

Multiple Protocols Support

Docking with various mainstream PLC brands, multiple IoT protocols, and industrial protocols

Supports rich interfaces such as RS485/RS232/DI/DO/CAN(Interfaces vary per model)

Rich Hardware Interfaces

Rich interfaces such as RS485/RS232/DI/DO/CAN
(Interfaces vary per model)

Embedded Node-RED visual programming with nodes to represent complex hardware interfaces

Drag-and-Drop Programming

Embedded Node-RED visual programming with nodes to represent complex hardware interfaces

Remote management software enables remote management functions for on-site equipment

Remote Management

Remote management software enables remote management functions for on-site equipment

Supports 4G, network port, WiFi access Automatic reconnection

Switching Network

Supports 4G, network port, WiFi access
Automatic reconnection

industrial

Industrial Grade

Operate stably at -40°C~+85°C, double watchdogs, anti-static, surge prevention

Benefits

EG Gateway completes data cleaning, compression, and preliminary analysis at the edge. Only high-value data is transmitted to the cloud, reducing bandwidth consumption.

Multi-protocol enables the edge computing gateway to serve as the central hub for data collection. It can easily connect to various devices, including PLCs, networked devices, serial devices, and sensors.

Transport Layer Encryption: Supports TLS/SSL protocols to ensure that the data is not tampered with during transmission.
Double watchdogs Technology: Rapid recovery from failures to ensure high-speed and stable operation of the gateway.

Applications

By reducing latency, enhancing data security, reducing network load, optimizing system responsiveness, and improving operational efficiency, edge computing gateways have become a core technology for driving intelligent transformation in various industries.

The ER1000 industrial switch features a full Gigabit port design, ensuring high-speed and stable network transmission for industrial equipment
